MODEL SPECS |
Click on a technology to learn more.
Engine Management Technology |
Chassis Management Technology |
Maximum Power | 50.2 kW {68 PS} / 8,000 rpm |
Maximum Torque | 64 N.m {6.5 kgf.m} / 6,700 rpm |
Engine type | 4-stroke, Parallel Twin |
Displacement | 649cc |
Bore and Stroke | 83.0 x 60.0 mm |
Compression Ratio | 10.8:1 |
Ignition system | Digital |
Starting system | Electric starter |
Lubrication System | Forced lubrication (semi-dry sump) |
Transmission | 6-speed, return |
Primary reduction ratio | 2.095 (88/42) |
Gear ratio: 1st | 2.438 (39/16) |
Gear ratio: 2nd | 1.714 (36/21) |
Gear ratio: 3rd | 1.333 (32/24) |
Gear ratio: 4th | 1.111 (30/27) |
Gear ratio: 5th | 0.966 (28/29) |
Gear ratio: 6th | 0.852 (23/27) |
Final reduction ratio | 3.067 (46/15) |
Clutch type (Primary) | Wet multi-disc, manual |
Driving system | Chain |
Frame type | Trellis, high-tensile steel |
Front Suspension | ø41 mm telescopic fork |
Rear Suspension | Horizontal Back-link, single-shock with adjustable spring preload |
Front Wheel Travel | 125 mm |
Rear Wheel Travel | 130 mm |
Rake | 24º |
Trail | 100 mm |
Steering angle (left/right) | 35º / 35º |
Front Tire | 120/70ZR17M/C (58W) |
Rear Tire | 120/70ZR17M/C (58W) |
Front Brake Type | Dual semi-floating 300 mm petal discs |
F. Brake Effective Diam. | 272 mm |
Rear Brake | Single ø220 mm petal disc |
R. Brake Effective Diam. | 186 mm |
Dimensions (LxWxH) | 2,065 x 800 x 1,115 mm |
Wheelbase | 1,405 mm |
Road clearance | 125 mm |
Seat height | 820 mm |
Curb weight* | 187 kg |
Fuel tank capacity | 12 litres |
Fuel Consumption | 5.3 L/100km |
Warranty | 24 months |
*Curb weight includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
**Estimated dry weight does not include all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
