MSRP NON-ABS0 VND
-
/
-
MSRP ABS514,600,000 VND
Specifications and pricing are subject to change.
MODEL SPECS |
Premium Brembo M50
monobloc calipers
Öhlins rear shock with
remote preload adjuster
| Maximum Power | 104.5 kW {142 PS} / 10,000 rpm |
| Maximum Torque | 111.0 Nm {11.3 kgfm} / 7,300 rpm |
| Engine type | Liquid-cooled, 4-stroke In-Line Four |
| Displacement | 1,043 cm³ |
| Bore and Stroke | 77.0 x 56.0 mm |
| Compression Ratio | 11.8:1 |
| Fuel System | Fuel injection: ø38 mm x 4 with oval sub-throttles |
| Ignition system | B&C (TCBI EL. ADV. D.) |
| Starting system | EL. Starter |
| Lubrication System | Forced Lub. Wet |
| Transmission | 6-speed, return |
| Primary reduction ratio | 1.627 (83 /51) |
| Gear ratio: 1st | 2.600 (39 /15) |
| Gear ratio: 2nd | 1.950 (39 /20) |
| Gear ratio: 3rd | 1.600 (24 /15) |
| Gear ratio: 4th | 1.389 (25 /18) |
| Gear ratio: 5th | 1.238 (26 /21) |
| Gear ratio: 6th | 1.107 (31 /28) |
| Final reduction ratio | 2.867 (43 /15) |
| Clutch type (Primary) | Wet, multi-disc |
| Driving system | Chain |
| Frame type | Twin-tube, aluminium |
| Front Suspension | ø41 mm inverted fork with compression and rebound damping and spring preload adjustability |
| Rear Suspension | Horizontal Back-link, Öhlins S46 gas-charged shock with rebound damping and remote spring preload adjustability |
| Front Wheel Travel | 120 mm |
| Rear Wheel Travel | 131 mm |
| Rake | 24.5° |
| Trail | 101 mm |
| Steering angle (left/right) | 29° / 29° |
| Front Tire | 120 /70ZR17M /C (58W) |
| Rear Tire | 190 /50ZR17M /C (73W) |
| Front Brake Type | Dual semi-floating ø310 mm Brembo discs |
| F. Brake Effective Diam. | 284 mm |
| Rear Brake | Single ø250 mm disc |
| R. Brake Effective Diam. | 214 mm |
| Wheelbase | 1,435 mm |
| Dimensions (LxWxH) | 2,045 x 790 x 1,055 mm |
| Wheelbase | 1,435 mm |
| Road clearance | 125 mm |
| Seat height | 815 mm |
| Curb weight* | 221 kg |
| Fuel tank capacity | 17 litres |
| Fuel Consumption | 6.0 L/100km |
| Warranty | 24 months |
*Curb weight includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
**Estimated dry weight does not include all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
KAWASAKI CARES: Always wear a helmet, eye protection, and proper apparel. Never ride under the influence of drugs or alcohol. Read Owner’s Manual and all on-product warnings. Professional rider shown on a closed course. 2019 Kawasaki Motors Vietnam Co., Ltd.
Specifications subject to change.
